Sang Hyun Park

Artificial lattices have been used as a platform to extend the application of topological band theory beyond electronic systems. Here, using the two-dimensional Lieb lattice as a prototypical example, we show that an array of disks which each support localized plasmon modes gives rise to an analog of the quantum spin-Hall state enforced by a synthetic time-reversal symmetry. We find that the plasmonic modes naturally possess a synthetic spin degree of freedom which leads to a spin-dependent second-neighbor coupling mechanism mediated by interorbital coupling. This interaction introduces a nontrivial 𝑍2 topological order and gaps out the Bloch spectrum. A faithful mapping of the plasmonic system onto a tight-binding model is developed and shown to capture its essential topological signatures. Full wave numerical simulations of graphene disks arranged in a Lieb lattice confirm the existence of propagating helical boundary modes in the nontrivial band gap.

Surface plasmons, which allow tight confinement of light, suffer from high intrinsic electronic losses. It has been shown that stimulated emission from excited electrons can transfer energy to plasmons and compensate for the high intrinsic losses. To-date, these realizations have relied on introducing an external gain media coupled to the surface plasmon. Here, we propose that plasmons in two-dimensional materials with closely located electron and hole Fermi pockets can be amplified, when an electrical current bias is applied along the displaced electron-hole pockets, without the need for an external gain media. As a prototypical example, we consider WTe 2 from the family of 1T $^\prime $ ′ -MX 2 materials, whose electronic structure can be described within a type-II tilted massive Dirac model. We find that the nonlocal plasmonic response experiences prominent gain for experimentally accessible currents on the order of mA μ m −1 . Furthermore, the group velocity of the plasmon found from the isofrequency curves imply that the amplified plasmons are highly collimated along a direction perpendicular to the Dirac node tilt when the electrical current is applied along it.

The coupling of plasmons and vibrational modes has been routinely observed in graphene and other 2D systems in both near-field and far-field spectroscopy. However, the relation between coupling strength and modal losses, and exceptional point physics has not been discussed. Here we apply a non-Hermitian framework to a model system of molecular layers on graphene and show that the transition point between strong and weak coupling regimes coincides with the exceptional point of non-Hermitian physics. We further show that the exceptional point can be conveniently located by changing the incident angle of the light and the graphene Fermi energy. Finally, we show that enhanced spectral sensitivity is obtained from small changes in molecular film thickness when the system is tuned to the exceptional point.

Exceptional points (EPs), also known as non-Hermitian degeneracies, have been observed in parity-time symmetric metasurfaces as parity-time symmetry breaking points. However, the parity-time symmetry condition puts constraints on the metasurface parameter space, excluding the full examination of unique properties that stem from an EP. Here, we thus design a general non-Hermitian metasurface with a unit cell containing two orthogonally oriented split-ring resonators (SRRs) with overlapping resonance but different scattering rates and radiation efficiencies. Such a design grants us full access to the parameter space around the EP. The parameter space around the EP is first examined by varying the incident radiation frequency and coupling between SRRs. We further demonstrate that the EP is also observable by varying the incident radiation frequency along with the incident angle. Through both methods, we validate the existence of an EP by observing unique level crossing behavior, eigenstate swapping under encirclement, and asymmetric transmission of circularly polarized light.
